MB-12/22 PLC Controlled High Speed Paper Cup Machine
As a new model in our company, MB-12/22 fully automatic PLC controlled high speed paper cup forming machine is the first patented device domestically. It is produced by combining foreign high speed paper cup machinery technology and years of paper cup machinery manufacturing experience. PLC controlled paper cup machine adopts different turntable processing modes for the bottom and rim of cup to transform the original three-turntable model into two turntable model. This can effectively reduce the working stroke of the high speed paper cup forming machine This paper cup making equipment mainly includes ultrasonic sealing head for paper cup side welding, hot air system for the bottom, touch screen, PLC controller, motor, paper cup deliver system and alarm system. In addition to PLC controlled paper cup machine, we also produce single or double PE coated paper cup making machine, ultrasonic double side PE paper cup forming machine and cup top flatten machine.
1. MB-12/22 high speed paper cup forming machine is characterized by stable performance, easy operation, convenient use and clear touch screen.
2. PLC controlled paper cup machine features stable operation, good product quality and high rate of graded product even while working at high speed.
3. It is especially suitable for making tall paper cups.
4. Possessing automatic discharging, counting, stacking and other functions and owning automatic oil lubrication system, this high speed paper cup forming machine has become the best choice for many customers to make paper cups.
Packaging and Transportation
We use wooden cases to package PLC controlled paper cup machines, which is convenient for sea transportation. For maintenance, customers can consult the operation manual.
Parameters of MB-12/22 PLC Controlled High Speed Paper Cup Forming Machine
|Specification||6 to 32 oz|
|Paper Material||150 to 400 gsm|
|Output||60 to 80 pcs/min|
|Total Power||13 kW, 380 V, 50 Hz|
|Air Consumption||0.4 m³/min|
|Overall Dimension||2800 mm × 1600 mm × 1600 mm|
Ruian Mingbo Machinery Co., Ltd. is a professional manufacturer of high speed paper cup forming machines in China. In addition to PLC controlled paper cup machine, our company also offers paper bowl machine, paper bucket forming machine, paper plate machine, die cutting machine, cup lid machine, flexo printing machine, etc. Our paper cup making machines have been exported to Jordan, Algeria, Qatar, India, Indonesia, Taiwan, Libya, Russia, and so on.
